GEA has a reputation for fulfilling the high hygienic demands made by the food and beverages industry with its production machinery. The company’s Ahaus (Germany) site produces not only milk and juice processing systems but also heat exchangers for heating and cooling in aseptic procedures. The fitted tubes inside the pressure vessels coming into contact with the products are supplied by Schoeller Werk in Hellenthal, Germany. The specialist for longitudinally welded stainless steel tubes has also convinced the managers at GEA with a refined logistics concept. The tubes can be delivered quickly within just one week, giving GEA scope for the best possible response to short-term fluctuations in demand.
GEA has a global workforce of nearly 18,000 employees, making it one of the largest suppliers of process technology for the food industry and a wide range of other sectors. The international technology group focuses on processing systems and components for sophisticated production processes in various end-user markets. The group generated consolidated turnover of around 4.6 billion Euro in 2017, with about 70% coming from the food and beverages industry with its long-term growth prospects.
Heat exchangers at the heart
At its Ahaus site, GEA produces not only milk and juice processing systems but also heat exchangers for heating and cooling in aseptic procedures. They are
at the heart of all processing systems for heating, cooling, pasteurising or UHT heating. The brewery and beverage industries are typical applications for GEA heat exchangers where they are used for wort cooling/heating, flash pasteurization of beer and yeast, and the heating and cooling of wine. Users can choose from a large number of different heat exchanger designs, depending on the required production capacity and the physical properties of the product. GEA also develops customised designs on request to suit each specific application. Regardless of the individual application, all heat exchangers function according to the same principle: the product flows through several straight inner tubes with a heat transfer medium flowing around them in a jacket tube. This structure equalises the differing heat expansion rates between the inner tube package and the jacket caused by high differences in temperature.
at the heart of all processing systems for heating, cooling, pasteurising or UHT heating. The brewery and beverage industries are typical applications for GEA heat exchangers where they are used for wort cooling/heating, flash pasteurization of beer and yeast, and the heating and cooling of wine. Users can choose from a large number of different heat exchanger designs, depending on the required production capacity and the physical properties of the product. GEA also develops customised designs on request to suit each specific application. Regardless of the individual application, all heat exchangers function according to the same principle: the product flows through several straight inner tubes with a heat transfer medium flowing around them in a jacket tube. This structure equalises the differing heat expansion rates between the inner tube package and the jacket caused by high differences in temperature.
Pressure Equipment Directive 97/23/EC
All heat exchangers have to fulfil the strict conditions imposed by the Pressure Equipment Directive 97/23/ EC. GEA was therefore looking for a reliable supplier of top quality longitudinally welded stainless steel tubes for use as product-conveying inner tubes fitted inside the heat exchangers. “We know exactly what we need in terms of the tubes used in our aseptic systems”, explains Christoph Oberrecht, purchaser PSC EMEA Central Procurement at GEA. “In addition to high quality and the right value for money, it was also important for us to find an appropriate concept for the logistics.”
Longitudinally
Longitudinally
Tubes to food industry standards
Since 2016, the industrial plant manufacturer in Ahaus has been the customer of the specialist for longitudinally welded stainless steel tubes from Hellenthal (Eifel). Schoeller Werk produces stainless steel tubes pursuant to the food industry standard DIN EN 10357 BC and supplies them according to demand on the basis of a refined logistics concept. The DIN EN 10217-7 compliant tubes made of austenite 1.4571 fulfil the Pressure Equipment Directive 97/23/EC. The tubes in the heat exchangers are in direct contact with the product and therefore also fulfil the special hygiene requirements imposed by the food and beverages industry,
About Schoeller Werk GmbH & Co. KG Schoeller Werk was founded in 1827 and is based in Hellenthal in the Eifel region of Germany where it has more than 1,000 employees. Its range of products includes TIG- and laser-welded stainless steel tubes, drawn precision tubes in straight bespoke or fixed lengths as well as annular tubes. Around 90 million metres of stainless steel tubing are made here every year for a wide variety of applications in the automotive, industrial and energy sectors.
including among others a weld factor of 1.0 and tube roughness of < 0.8 my. They are therefore also certified with certificate
About Schoeller Werk GmbH & Co. KG Schoeller Werk was founded in 1827 and is based in Hellenthal in the Eifel region of Germany where it has more than 1,000 employees. Its range of products includes TIG- and laser-welded stainless steel tubes, drawn precision tubes in straight bespoke or fixed lengths as well as annular tubes. Around 90 million metres of stainless steel tubing are made here every year for a wide variety of applications in the automotive, industrial and energy sectors.
including among others a weld factor of 1.0 and tube roughness of < 0.8 my. They are therefore also certified with certificate
APZ 3.1 B pursuant to DIN/ EN 10204.
Demand-driven logistics concept
Schoeller Werk supplies the tubes in a variety of dimensions. “The special thing about our collaboration with GEA is the logistics concept which has been drawn up together with the customer”, explains Nathalie Türffs, Head of Sales Industry II at Schoeller Werk. “We plan the production quantities according to demand. These are checked on a monthly basis, and safety stocks are taken into storage in quantities agreed with the customer.”
That is a great advantage for GEA as it saves storage costs. Furthermore, it also puts the company in a position to respond to short-term project business and the resulting fluctuations in demand. “Production of the tubes would take several weeks”, explains Christoph Oberrecht, purchaser at GEA. “In the framework of the logistics concept, the tubes are supplied usually just a few days after placing our purchase order. It helps of course that Schoeller Werk in Hellenthal is not far from our Ahaus site.”
Utmost satisfaction
GEA’s customers benefit from the extremely high quality of the heat exchanger systems, thanks primarily to the inner tubes made by Schoeller Werk. For the contact persons at GEA, the specialist for longitudinally welded stainless steel tubes is more than just a supplier. As a wellestablished company that looks back on a long tradition, Schoeller Werk also offers swift service and support, dealing reliably with any technological issues covering all aspects of the tubes.
